Winding Machine for Small Distribution Transformer
  • Winding Machine for Small Distribution Transformer
  • Winding Machine for Small Distribution Transformer
  • Winding Machine for Small Distribution Transformer
  • Winding Machine for Small Distribution Transformer

Winding Machine for Small Distribution Transformer

Payment Type:
L/C,T/T
Incoterm:
FOB,CFR,CIF,EXW
Min. Order:
1 Set/Sets
Transportation:
Ocean
Share:
Chat Now
  • Product Description
< >
Overview
Product Attributes

Model No.: ZRXJ-1100

Brand: YBBA

status: New

Out-of-warranty service: Video Technical Support, Online Support

Video factory inspection: Provided

Mechanical test report: Provided

Marketing type: Hot Product 2019

Core component warranty period: 1 Year

Core components: Motor

place of origin: China

Whether CNC machine tool: Cnc

warranty period: 1 Year

Core selling point: Famous Brand Motor

Where to provide local services (in which countries are there overseas service outlets): None

Applicable industry: Manufacturing Plant

Showroom location (in which countries are there sample rooms overseas): None

Function: Abrasion Resistance

Certification: CE

Demoulding: Automatic

Condition: New

Warranty: 12 Months

Automatic Grade: Automatic

Installation: Desktop

Driven Type: Electric

Mould Life: >1,000,000 Shots

Installation Capacity: 45KW

Supply Ability & Additional Information

Packaging: Seaworthy packing

Productivity: 20sets/month

Transportation: Ocean

Place of Origin: Shandong, China

Supply Ability: 200SETS/Year

Certificate: ISO

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF,EXW

Packaging & Delivery
Selling Units:
Set/Sets
Package Type:
Seaworthy packing

Purpose of the product:

ZRXJ-1100 series transformer Coil Winding Machine is specially designed for winding coil of medium and small distribution transformer, instrument transformer and reactors. It is also suitable to wind HV coil of amorphous core transformer.

Our coil Winding machine is the most advanced winding machine, which is designed as insulation requirement of ABB and SIEMENS transformer production program, bringing in the latest technology of B&R; and TOBOLY and combining with our newest designing thoughts as well experience. It is the most optimum choice to improve to efficiency and reduce the material cost using our machine.


Transformer Coil Winders

Main parts list

Inverter

Delta

Servo system

Delta

PLC

Siemens

Touch screen

Siemens

LV components

Schneider

Pneumatic components

Japan SMC

Linear rail

Taiwan HIWIN

Main Technical parameter

Model
Paramet 		ZRX-600 ZRX-800 ZRX-1100
Height of the coil ≤500mm ≤800mm ≤1100mm
Outer diameter of the coil ≤¢600mm ≤¢800mm ≤¢900mm
Inner diameter of the coil ≥¢80mm ≥¢80mm ≥¢80mm
Speed regulation mode Stepless variable speed Stepless variable speed Stepless variable speed
Operating speed 0-375r/min 0-375r/min
220r/min 		0-375r/min
220r/min
Wire specification 2 flat conductors≤3*12mm
Lacquered Wire:0.3mm-3mm 		2 flat conductors≤3*12mm
Lacquered Wire:0.3mm-3mm 		2 flat conductors≤3*12mm
Lacquered Wire:0.3mm-3mm
Operating torque ≤300N/M ≤300N/M ≤300N/M
Center height 850mm 850mm 850mm
Center-to-center distance of reel 250-800mm 250-1100mm 400-1300mm
Electrical control system Touch screen Touch screen Touch screen
Winding reel Square shaft 40*40 Square shaft 40*40 Square shaft 50*50
Rectangular coil diagonal length ≤700mm ≤900mm ≤1100mm
Workpiece weight ≤500KG ≤800KG ≤1000KG
Automatic wire aarraying function Min. Space of wire diameter adjustment 0.01mm Min. Space of wire diameter adjustment 0.01mm Min. Space of wire diameter adjustment 0.01mm


Packing details

1) Applying Anti-Rust Oil

2) Covering with stretch film

3) Covering aluminum air bag

4) Vacuuming air bags

5) Boxing all the pallet

6) Loading to the container

Packaging Shipping

Our service

--- Inquiry will be replied within 2 hours.

--- All the way tracking service offered from placing order to delivery.

--- We can provide professional guide installation.

--- One year warranty and all round after sale service.

--- Customized design and flow chart are available for our clients.

--- Independent R&D; team and strict & scientific management system.



Looking for ideal Transformer Coil Winders Manufacturer & supplier ? We have a wide selection at good prices to help you get creative. All the Expandable Winding Mandrel are quality guaranteed. We are China Origin Factory of Coil Winder Tensioner. If you have any question, please feel free to contact us.
